6507/7-4

Export: PDF icon PDF
  • General information

    General information
    Attribute Value
    Wellbore name
    Official name of wellbore based on Norwegian Offshore Directorate guidelines for designation of wells and wellbores.
    6507/7-4
    Type
    Wellbore type. Legal values: EXPLORATION, DEVELOPMENT, OTHER (see 'Purpose' for more information)
    EXPLORATION
    Purpose
    Final classification of the wellbore.

    Legal values for exploration wellbores:
    WILDCAT, APPRAISAL, WILDCAT-CCS, APPRAISAL-CCS.

    Legal values for development wellbores:
    OBSERVATION, PRODUCTION, INJECTION, INJECTION-CCS, OBSERVATION-CCS.

    Legal values for other wellbores:
    SOIL DRILLING (drilling in connection with track surveys and other subsurface surveys to investigate the soil conditions prior to placement of facilities),
    SHALLOW GAS (drilling to investigate shallow gas before the first 'real' drilling on the location),
    PILOT (drilling to investigate the geology and fluid connectors for location of the main wellbore),
    SCIENTIFIC (drilling according to Law of Scientific research and exploration),
    STRATIGRAPHIC (driling according to Law of Petroleum activities §2-1).
    APPRAISAL
    Status
    Status for the wellbore. Legal values are:

    BLOWOUT: A blowout has occurred in the well.
    CLOSED: A development wellbore that has been closed in a shorter or longer periode. Also applies to development wellbores where drilling is completed, but production/injection has not yet been reported.
    DRILLING: The well is in the drilling phase - can be active drilling, logging, testing or plugging,
    JUNKED: The drilling operation has been terminated due to technical problems.
    P&A: Exploration: The well is plugged and abandoned, and can not be reentered for further use. Development wells: The production/injection from/to the well is stopped and the well is plugged. The wellhead is removed or else made unavailable for further well operations.
    PLUGGED: The wellbore has been plugged, but the upper parts of the wellbore can be re-used. A sidetrack might be drilled at a later stage.
    PRODUCING: It was produced from the wellbore at the time of the operators last monthly report to the Norwegian Offshore Directorate.
    INJECTING: It was injected to the wellbore at the time of the operators last monthly report to the Norwegian Offshore Directorate.
    PREDRILLED: The upper part of the well has been drilled, usually as part of a batch-drilling campaign covering several wellbores.
    RE-CLASS TO DEV: Exploration wellbore that is reclassified to a development wellbore.
    RE-CLASS TO TEST: Exploration wellbore that is reclassified to test production.
    SUSPENDED: The drilling operation in the wellbore has been temporarily stopped. The current plan is to continue drilling later on.
    P&A
    Factmaps in new window
    Main area
    Name of the area on the Norwegian Continental Shelf where the wellbore is located. Legal values: BARENTS SEA, NORWEGIAN SEA, NORTH SEA.
    NORWEGIAN SEA
    Field
    Name of the field the wellbore is related to.
    Discovery
    Name of the discovery the wellbore is related to.
    Well name
    Official name of the parent well for the wellbore based on Norwegian Offshore Directorate guidelines for designation of wells and wellbores.
    6507/7-4
    Seismic location
    Position of spud location on seismic survey lines. SP: shotpoint.
    BP 83 - 308 SP. 689
    Production licence
    Official designation of the production licence the wellbore was drilled or planned to be drilled from ( well head posistion).
    Drilling operator
    Name of the licensee starting the drilling operation on behalf of the active production license (well head position). This will usually equal the operator of the production license.
    Conoco Norway Inc.
    Drill permit
    The drilling permit number together with the version of the drilling permit as stated in the drilling permit granted by the Norwegian Offshore Directorate.
    490-L
    Drilling facility
    Norwegian Offshore Directorate's name of the facility which the wellbore was drilled from.
    Drilling days
    Number of days from wellbore entry to wellbore completion.
    69
    Entered date
    The date when he wellbore was spudded. For sidetracks: The date when new formation was drilled by kicking off from the mother-wellbore,
    06.11.1985
    Completed date
    Exploration wellbores from moveable facilities:
    For floating facilities - date when anchor handling is started. For jackups - date the jacking-down started. Exploration wellbores from fixed facilities and all development wellbores:
    Date when the wellbore is at total depth, and last casing, liner or screen is set. In case of immediate plugging of the wellbore, completed date equals the date the last plug i set in the wellbore.
    Date when the wellbore is at total depth, and last casing, liner or screen is set. In case of immediate plugging of the wellbore, completed date equals the date the last plug i set in the wellbore.
    13.01.1986
    Release date
    Date when raw data which has been reported to the authorities from the wellbore is not confidential any longer. Normally 2 years after finishing the drilling. May be earlier if the area of the production license is relinquished.
    13.01.1988
    Publication date
    Date quality control of the wellbore information was completed, so it can be published on the internet as a 'Well Data Summary Sheet' wellbore with more information available than other wellbores.
    18.12.2008
    Purpose - planned
    Pre-drill purpose of the wellbore. Legal values for exploration wellbores: WILDCAT, APPRAISAL, WILDCAT-CCS, APPRAISAL-CCS. Example of legal values for development wellbores: OBSERVATION, PRODUCTION, INJECTION.
    APPRAISAL
    Reentry
    Status whether the wellbore has been re-entered (YES) or not (NO). Re-entered wellbores are not included in the count when wellbores are presented in statistical overviews.
    NO
    Content
    For exploration wellbores, status of discovery.

    Legal values:
    DRY, SHOWS (trace amounts of hydrocarbons), GAS, GAS/CONDENSATE, OIL or OIL/GAS.
    SHOWS (GAS SHOWS, OIL SHOWS or OIL/GAS SHOWS) are detected as fluorescent cut (organic extract), petroleum odour, or visual stain on cuttings or cores, or as increased gas reading on the mud-loggers gas detection equipment.
    Legal values for WILDCAT-CCS and APPRAISAL-CCS: WATER

    For development wellbores, type of produced/injected fluid.
    Legal values:
    WATER, CUTTINGS, NOT AVAILABLE, OIL, GAS/CONDENSATE, OIL/GAS, CO2, GAS, WATER/GAS, NOT APPLICABLE.
    OIL/GAS
    Discovery wellbore
    Indicator which tells if the wellbore made a new discovery. Legal values: YES, NO. Prior to press-release or other information regarding drilling results, the indicator will be “NO” as a default.
    NO
    1st level with HC, age
    Age of lithostratigraphic unit, 1st level, where hydrocarbons were encountered. Examples of legal values: CRETACEOUS, EARLY CRETACEOUS, LATE JURASSIC, EOCENE. See also Norwegian Offshore Directorate bulletins.
    MIDDLE JURASSIC
    1st level with HC, formation
    Name of lithostartigraphic unit, 1st level, where hydrocarbons were encountered. Shown only for released wells. Examples of legal values: BASEMENT, COOK FM, EKOFISK FM, HEIMDAL FM, SANDNES FM, SOGNEFJORD FM, TARBERT FM, BRENT GP. See also Norwegian Offshore Directorate bulletins.
    ILE FM
    Kelly bushing elevation [m]
    Elevation of the rotary kelly bushing (RKB) above mean sea level.
    25.0
    Water depth [m]
    Depth in metres betweem mean sea level and sea floor.
    345.0
    Total depth (MD) [m RKB]
    Total measured length of wellbore from kelly bushing to total depth (driller's depth).
    2850.0
    Final vertical depth (TVD) [m RKB]
    Vertical elevation from total depth to kelly bushing. Shown only for released wells. Referred to as true vertical depth (TVD).
    2850.0
    Maximum inclination [°]
    Maximum deviation, in degrees, from a vertical well path.Shown only for released wells.
    2.8
    Bottom hole temperature [°C]
    Estimated temperature at final total depth of the wellbore. Shown only for released wells. See discription.
    98
    Oldest penetrated age
    Age (according to Geologic Time Scale 2004 by F. M. Gradstein, et al. (2004)) of the oldest penetrated formation. May differ from age at TD for example in deviated wellbores. Examples of legal values: CRETACEOUS, EARLY CRETACEOUS, LATE JURASSIC, EARLY PERMIAN, EARLY TRIASSIC, EOCENE.
    EARLY JURASSIC
    Oldest penetrated formation
    Name of the oldest lithostratigraphic unit penetrated by the wellbore. Shown only for released wells. In most wellbores this is formation or group at total depth. May differ from formation or group at TD for example in wellbores drilled with high deviation or through faults. Examples of legal values: AMUNDSEN FM, BALDER FM, BASEMENT, BLODØKS FM, BRYNE FM, BURTON FM, COOK FM, DRAKE FM, DRAUPNE FM, EKOFISK FM, DUNLIN GP.
    TILJE FM
    Geodetic datum
    Reference system for coordinates. Example of legal values: ED50.
    ED50
    NS degrees
    Geographic coordinate of the wellhead, north-south degrees.
    65° 19' 11.56'' N
    EW degrees
    Geographic coordinate of the wellhead, east-west degrees.
    7° 15' 44.99'' E
    NS UTM [m]
    Universal Transverse Mercator coordinate of the wellhead, north-south.
    7245402.39
    EW UTM [m]
    Universal Transverse Mercator coordinate of the wellhead, east-west.
    419050.20
    UTM zone
    Universal Transverse Mercator zone. Examples of legal values: 31, 32, 33, 34.
    32
    NPDID wellbore
    Norwegian Offshore Directorate's unique id for the wellbore.
    853
  • Wellbore history

    Wellbore history
    General
    Appraisal well 6507/7-4 was drilled in the northern part of the Haltenbanken area, some 190 km west of the Norwegian coast. It was drilled to evaluate the "B" prospect in the intensely faulted zone that lies at the intersection of the Nordland Ridge in the northeast and the Halten Terrace in the south. The prospect was in a southward plunging horst block formed by a Late Jurassic tensional fault system. Well 6507/7-4 was drilled in a down dip position relative to discovery well 6507/7-2 and the prime objective was to establish the oil/water contact in sandstones of the Middle Jurassic Tomma Formation.
    Operations and results
    Well 6507/7-4 was spudded with the semi-submersible installation Nortrym on 6 November 1985 and drilled to TD at 2850 m in the Early Jurassic Tilje Formation. Due to adverse weather conditions in the first week of operations spudding of the well was made difficult, and 4.5 days were lost as WOW in this phase. Swelling clays (gumbo) caused some problems in the 17 1/2" section. The upper part of the core barrel in core no 3 ruptured, unfortunately exactly in the section around OWC. Otherwise operations proceeded without significant problems. The well was drilled with sea water and gel sweeps down to 1021 m and with gypsum/polymer mud from 1021 m to TD.
    The Tomma Formation sandstones (Garn Formation) was prognosed at 2455 m, and encountered at 2449 m. The Garn Formation was found oil bearing. Oil shows were observed on core no 1 from 2444.5 m (driller's depth) down to 2490.7 m. It was described as a uniform strong yellow show with even white cut down to 2463 m when the show became more patchy with streaming cut. When retrieving core no 3 the upper part from 2491 to 2503.6 m of the core barrel ruptured so that the amount and sequence of recovery in this section was made uncertain. But shows were seen in this section and was confirmed by electric logs, DST and very good RFT pressure data, which gave an O/W contact at 2498 m. No oil show was seen below 2503.6 m driller's depth (2509.1 m logger's depth).
    Twelve cores were cut from 2435 m down to 2766.40 m with 98.2% recovery. A water sample was taken on wire line at 2525 m.
    The well was permanently abandoned on 13 January 1986 as an oil and gas appraisal well.
    Testing
    Three drill stem tests were undertaken, all of them testing the oil-bearing sands of the Tomma Formation (Garn Formation). The intervals perforated were 2494-2499 m (DST 1), 2470-2477 m (DST 2) and 2449-2465 m (DST 3). At stabilized conditions with a 152/64 inch choke the maximum production was 6504 BOPD (1032 Sm3 oil/day) with an oil gravity of 29 deg API. Associated gas production was 3217 MCFGPD (91100 Sm3 gas/day) with a gravity of 0.696 at 60 deg F. The average DST temperatures at mid perforation were: 88.6 deg C (DST 1), 87.7 deg C (DST 2), and 87.2 deg C (DST 3).
  • Cuttings at the Norwegian Offshore Directorate

    Cuttings at the Norwegian Offshore Directorate
    Cuttings available for sampling?
    YES
    Cuttings at the Norwegian Offshore Directorate
    Cutting sample, top depth [m]
    Cutting samples, bottom depth [m]
    470.00
    2846.00
  • Cores at the Norwegian Offshore Directorate

    Cores at the Norwegian Offshore Directorate
    Core sample number
    Core sample - top depth
    Core sample - bottom depth
    Core sample depth - uom
    1
    2435.0
    2461.0
    [m ]
    2
    2463.0
    2490.7
    [m ]
    3
    2491.0
    2518.5
    [m ]
    4
    2518.5
    2546.0
    [m ]
    5
    2546.0
    2573.5
    [m ]
    6
    2573.0
    2601.1
    [m ]
    7
    2601.5
    2629.4
    [m ]
    8
    2629.0
    2656.8
    [m ]
    9
    2657.0
    2684.8
    [m ]
    10
    2684.0
    2712.1
    [m ]
    11
    2712.0
    2739.6
    [m ]
    12
    2739.5
    2766.7
    [m ]
    Cores at the Norwegian Offshore Directorate
    Total core sample length [m]
    330.6
    Cores at the Norwegian Offshore Directorate
    Cores available for sampling?
    YES
  • Core photos

    Core photos
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2435-2461m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2435-2461m
    2435-2461m
    2435-2461m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2465-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2465-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    Core photo at depth: 2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    2464-2490m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    2491-2518m
    Core photo at depth: 2491-2518m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2491-2518m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    2518-2546m
    Core photo at depth: 2518-2546m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2518-2546m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2546-2573m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2546-2573m
    2546-2573m
    2546-2573m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    2573-2601m
    Core photo at depth: 2573-2601m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2701-2629m
    Core photo at depth: 2701-2629m
    2573-2601m
    2601-2629m
    2601-2629m
    2701-2629m
    2701-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
    2601-2629m
    2601-2629m
    2601-2629m
    2601-2629m
    2601-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
    Core photo at depth: 2601-2629m
